Plinius P10 2ch 200W 8ohm Power Amp
The Plinius P10 has a level of sophistication rarely found in such a cost effective product. This amplifier has separate input and driver stage power supply regulation and it is an amplifier capable of true high-end performance.
The large toroidal transformer will allow Plinius’ P10 to deliver power levels in excess of 200 watts per channel into 8 Ohms. Difficult speaker loads are driven with ease to the most satisfying levels, while maintaining control and finesse.
Partnered with the Plinius Kaitaki preamplifier these stable mates will combine to perform at the highest level. The Plinius P10 is also highly suited to multiple custom installation use featuring a Home Theatre trigger bypass.
Specifications:
| POWER | 200 watts RMS per channel into 8 ohms. 300 watts RMS per channel into 4 ohms. Both channels driven from 20Hz to 20kHz at less than 0.2% total harmonic distortion |
| FREQUENCY RESPONSE | 20Hz to 20kHz +/–2dB -3dB at 5Hz and –3dB at 70kHz |
| DISTORTION | Typically <0.05% THD at rated power 0.2% THD and IM worst case prior to clipping |
| CURRENT OUTPUT | 40A short duration peak per channel Fuse protected |
| SLEW RATE | 50V/µs
|
| HUM & NOISE | 90dB below rated output 20Hz to 20kHz unweighted
|
| INPUT IMPEDENCE | 47k ohms
|
| GAIN | RCA Inputs: 32dB XLR Inputs: 38dB |
| POWER/CURRENT CONSUMPTION | 600W 0.4A (92W) Class AB Idle 0.14A (32W) Standby |
| DIMENSIONS | Height: 120mm (4 3/4”) Width: 450mm (17 3/4”) Depth: 400mm (15 3/4”) Weight: 14kg (30lbs) |
