1. Brand New Factory Sealed
2. Gryphon Zena Preamplifier Ex-Demo- Condition 9/10
2. Gryphon Zena Preamplifier + Zena DAC (Factory Installed) - Condition 8/10
PRODUCT DETAILS
Electrical
Output level balanced, max- 23Vrms, +29,5dBu
Noise, Unweighted, 20-20000hz- < -90dBu
Noise, A-weighted- < -94dBu
Distortion (THD+N)- < 0,005%
Gain- +18dB
Bandwidth (-3dB)- 0 - 1MHz
Channel Separation- Infinite
Input impedance, balanced (20-20000Hz)- 50KOhm
Input impedance, single ended (20-20000Hz)- 25KOhm
Output impedance (20-20000Hz)- 15Ohm
Balanced inputs, pr. channel- 2 x XLR
Single ended inputs, pr. channel- 3 x RCA
Balanced outputs, pr. channel- 1 x XLR
Single ended outputs, pr. channel- 2 x RCA (sub + tape out)
Power consumption (Stand-by)- < 0.5W
Power consumption (Maximum)- 50 W
Power consumption (Idle)- 50W
Power Supply Capacity- 2 x 26000 uF
No. of AC inlets / cable plug type- 1x IEC C13
Mechanical
Size (W x H x D) cm, net- 48x16.9x40
Weight, net (without optional modules)- 12.1 kg
Shipping weight and dimensions (L x W x H)- 17 kg, 56x53x31cm
